In a mobile environment, you can move left and right to see the contents (tables).
| Motor part number | - | 16ZWWC40L | |
|---|---|---|---|
| Motor size | mm | 16 | |
| Rated voltage | V | 12 | |
| Rated current | A | 2.6 | |
| Lead screw pitch | mm | 1.27 | |
| Standard stroke (customizable) | mm | 30 | |
| Maximum stroke | mm | 40 | |
| Maximum speed | mm/s | 20 | |
| Rated thrust | N | 200 | |
| Peak thrust (short-time) | N | 400 | |
| Gear ratio | - | 5.3, 28 | |
| Weight | g | 131.4 | |
| Overall dimensions | mm | Φ16 × 131.3 | |
| Operating temperature | ℃ | −20 ~ +50 | |
| Repeatability | mm | ±0.08 | |
| Encoder type | - | Incremental magnetic encoder | |
| Number of channels | - | 3 | |
| Encoder supply voltage | V | 5 | |
| Resolution | - | 1024 | |
The above data is based on a gear ratio of 28:1.
