Motor part number	VCXR-97-20-11.69-001
Stroke	mm	20
Continuous Force	N	11.69
Peak Force	N	35.1
Force Constant	N/A	8.35
Back EMF Constant	V/m/s	8.35
Resistance	Ω	3.7 ±10%
Inductance	mH	1.24 ±20%
Electrical Time Constant	ms	0.35
Continuous Current (Coil at 100℃)	A	1.4
Peak Current	A	4.2
Max. Coil Temperature	℃	155
Coil Assembly Mass	g	45
Magnet Weight	g	496
Coil Clearance	mm	0.6
Insulation Class	-	B
